Venice 95u inward-opening and tilt-and-turn windows
The Venetian 95u system window is a high-end inward-opening and inward-reversing window that combines ultra-narrow frame, concealed sash design, extremely high strength and ultimate energy efficiency. It is made of 6060-T66 ultra-precise alloy profiles with a wall thickness ranging from 1.8mm to 5.0mm (the key load-bearing part reaches 5.0mm). The visible area of the sash is only 52mm, while the combined visible area of the frame and sash is 77.6mm. Combined with the 73° bevel cutting process, it achieves a minimalist and transparent visual effect. It is equipped with German Vihagen wireless non-base handle + multi-lock point all-stainless steel U-slot hardware, with a load-bearing capacity of up to 300kg and a RC3 level anti-pickage grade. The insulation system uses 44mm PA66-GF25 insulation strips + German Teno Wind Spanish special-shaped insulation strips, and the sealing rubber strip is Jiangyin Haida rubber strip + permanent anti-retraction clamping rubber strip. The entire window has multiple advanced technologies such as five sealing layers, siphon drainage, eight strengthening ribs, etc., and is suitable for scenarios such as villas, high-end residences, and commercial spaces.
